23 Charles Gardens
Bournemouth
Dorset
BH10 5EH
Thank you for asking us to quote for your new project. Please find our pricing breakdown below.
| Item |
QTY
|
UNIT
|
TOTAL
|
|
|---|---|---|---|---|
| 1 |
Site strip
To strip site 400m2 up to 100mm from existing levels and cart away inert spoil only (if required).
|
56 M3
|
£35.00
|
£1,960.00
|
| 2 |
Temporary Haul Road
To supply and fit up to 150mm of 6F5 hardcore over existing ground to form temporary haul Road.
|
150 M2
|
£16.00
|
£2,400.00
|
|
£4,360.00
|
||||
|
We have allowed inert material only. |
||||
|---|---|---|---|---|
| Item |
QTY
|
UNIT
|
TOTAL
|
|
| 1 |
Reduce dig
To reduce dig 230m2 of oversite up to 450mm below existing levels and cart away inert arisings.
|
145 M3
|
£29.00
|
£4,205.00
|
|
£4,205.00
|
||||
|
All foundations based on drawings 21336-GAP-2A-00-DR-S-1010, 1011, 0010 and 19-188-01, 02, 12 |
||||
|---|---|---|---|---|
| Item |
QTY
|
UNIT
|
TOTAL
|
|
| 1 |
Setting Out
To set out Foundations and below ground blockwork following pour
|
3 Visit
|
£400.00
|
£1,200.00
|
| 2 |
450mm Strip Foundations
To excavate strip foundations up to 1000mm deep and 450mm wide. To fill with 300mm of GEN 3 concrete and cart away surplus inert arising's.
|
41 Lm
|
£75.00
|
£3,075.00
|
| 3 |
600mm Strip Foundations
To excavate strip foundations up to 1000mm deep and 600mm wide. To fill with 300mm of GEN 3 concrete and cart away surplus arising's.
|
79 Lm
|
£110.00
|
£8,690.00
|
| 4 |
Extra Over Concrete
To supply and fit extra over concrete, spoil away and labour if deeper excavations are required.
|
|
|
|
| 5 |
Cavity Fill 125/450
To supply and fit GEN1 concrete to cavities 125mm wide and 450mm deep.
|
79 Lm
|
£18.00
|
£1,422.00
|
| 6 |
Block and Beam Floor
To supply and fit concrete block and beam floor as manufacturers design. (To Follow)
|
1
|
£0.00
|
£0.00
|
| 7 |
Below floor Foul water drain
To supply and fit 110mm PVCu drainage on a bed and surround of 10mm pea shingle, concert surround to joints and bends, collar an cap.
|
49 Lm
|
£62.00
|
£3,038.00
|
| 8 |
Bellow floor ducting water
To supply and fit 100mm blue twin wall water duct from building face to internal position.
|
9 Lm
|
£18.00
|
£162.00
|
| 9 |
Bellow floor ducting Electric
To supply and fit 100mm twin wall duct from external face to internal postion
|
9 Lm
|
£18.00
|
£162.00
|
|
£17,749.00
|
||||
|
All drainage based on drawings C1659-P-100-REVP May 2021 |
||||
|---|---|---|---|---|
| Item |
QTY
|
UNIT
|
TOTAL
|
|
| 1 |
Surface water drain 110
To supply and fit 110mm PVCu drainage and fittings up to 1.2m deep on a bed and surround of 10mm pea shingle. To backfill with arising's and cart away surplus spoil.
|
85 Lm
|
£62.00
|
£5,270.00
|
| 2 |
Surface water inspection chamber 300
To supply and fit PVCu 300mm diameter inspection chambers, risers and lid up to 600mm deep.
|
2 Each
|
£320.00
|
£640.00
|
| 3 |
Surface water inspection chambers 450
To supply and fit PVCu 450mm diameter inspection chamber, risers and lid up to 1.2m deep.
|
5 Each
|
£415.00
|
£2,075.00
|
| 4 |
Silt Trap
To supply and fit a PVCu 450mm diameter silt trap and lid up to 1m deep.
|
1 Each
|
£365.00
|
£365.00
|
| 5 |
Attenuation
To supply and fit R modular water storage units wrapped in a no porous Geotextile membrane wrap including vent size 5m x 1m x .04m
Provisional sum
|
1 Each
|
£2,500.00
|
£2,500.00
|
| 6 |
Foul water drain 110 external
To supply and fit 110mm PVCu drainage and fittings up to 1.2m deep on a bed and surround of 10mm pea shingle. To backfill with arising's and cart away surplus spoil.
|
33 Lm
|
£62.00
|
£2,046.00
|
| 7 |
Foul water inspection chamber 300
To supply and fit PVCu 300mm diameter inspection chambers, risers and lid up to 600mm deep.
|
1 Each
|
£320.00
|
£320.00
|
| 8 |
Foul water inspection chambers 450 external
To supply and fit PVCu 450mm diameter inspection chamber, risers and lid up to 1.2m deep.
|
5 Each
|
£415.00
|
£2,075.00
|
| 9 |
Water Main Service Trench
To excavate a 600mm wide 750mm deep trench for new water service. To install a as dug sand bed, water main sand and warning tape and backfill with excavated arising's.
|
25 Lm
|
£45.00
|
£1,125.00
|
| 10 |
Barrier Water main 25mm
To supply and fit 25mm barrier water main to each plot.
Please note water will be inserted into underfloor duct prior to floor construction and left on site for future use.
|
75 Lm
|
£15.50
|
£1,162.50
|
| 11 |
Electric Service
To excavate a 300mm x 500mm trench for new electric cable installed by others. To supply a sand bed and cover including warning tape and backfill with excavated arsing's
|
45 Lm
|
£20.00
|
£900.00
|
| 12 |
Gas Service
To excavate a 300mm x 500mm trench for new gas pipe installed by others. To supply a sand bed and cover including warning tape and backfill with excavated arsing's
|
50 Lm
|
£20.00
|
£1,000.00
|
| 13 |
Telecoms Service
To excavate a 300mm x 500mm trench for new telecoms ducting. To install ducting supplied by you. To supply a sand bed and cover including warning tape and backfill with excavated arsing's
|
50 Lm
|
£21.00
|
£1,050.00
|
|
£20,528.50
|
||||
|
External works for budget purposes only we will update the rates within 2 monhts of install. |
||||
|---|---|---|---|---|
| Item |
QTY
|
UNIT
|
TOTAL
|
|
| 1 |
Permeable paving Budget
Budget to supply and fit 60mm standard permeable paving on a porous free draing bed.
|
130 M2
|
£92.00
|
£11,960.00
|
| 2 |
Concrete Path Edgings
To supply and fit 915mm x 150mm x 50mm concrete edgings on a bed and surround of concrete
|
95 Lm
|
£27.00
|
£2,565.00
|
| 3 |
Paving slabs
To supply and fit 450mm x450mm textured paving slabs on a mortar bed on 100mm of compacted type 1
|
50 M2
|
£80.00
|
£4,000.00
|
| 4 |
Top soil
To supply and fit 150mm of screened soil to garden and planting areas
|
40 M3
|
£58.00
|
£2,320.00
|
| 5 |
External Wall foundations
To be confirmed.
|
25 Lm
|
£65.00
|
£1,625.00
|
|
£22,470.00
|
||||
| Payment Terms - Standard Valuation | |||
|---|---|---|---|
| Subtotal | £69,312.50 | ||
| No VAT | £0.00 | ||
| TOTAL | £69,312.50 | ||
